BOGEN MC-PCA2 94-5326-14 Printed Circuit Board

BOGEN MC-PCA2 94-5326-14 Printed Circuit Board

 Introduction

BOGEN MC-PCA2 94-5326-14 Printed Circuit Board

1. BOGEN MC-PCA2 94-5326-14 compatible with Multicom2000 intercom system host rack

2. As the main control board of the system, it carries the logical operation and processing of the entire machine

3. Equipped with RS232 communication interface, supporting upper computer debugging and configuration

4. Onboard storage unit, storing site configuration and system parameters

5. Hardware watchdog circuit, automatic fault reset protection system

6. Gold finger backplane insertion, easy rack insertion and maintenance

7. Panel LED indicator light, displaying operation, alarm communication status

8. Built in system self-test program to quickly identify board faults

9. Can work collaboratively with analog audio cards and site interface cards

10. Responsible for calling, broadcasting, and intercom business logic scheduling

11. Industrial grade PCB substrate, suitable for long-term operation of building cabinets

12. Backboard power supply, low overall power consumption, stable and reliable operation

13. Support multi site networking and expandable number of intercom points

14. Equipped with relay linkage output to achieve external interlocking signals

15. Compatible with system accessories of the same series, can be upgraded and replaced with hardware

BOGEN MC-PCA2 94-5326-14 printed circuit board is the main control board of Multicom2000 intercom and paging system, which controls the entire system business of building intercom and public broadcasting.

Product imag
