Delta Tau 603625-102A UMAC-CPCI Data System PCB

Delta Tau 603625-102A UMAC-CPCI Data System PCB

 Introduction

Delta Tau 603625-102A UMAC-CPCI Data System PCB

1. Delta Tau 603625-102A follows the 3U CPCI standard board specifications

2. Adapt UMAC-CPCI system backplane bus to achieve high-speed data exchange

3. Equipped with DSP motion processing unit for multi axis motion data computation

4. Onboard SRAM storage, caching program and motion parameter data

5. Supports UBUS backplane communication and can be connected to multiple types of UMAC expansion cards

6. Hardware watchdog circuit, automatic protection reset for system abnormalities

7. Multi channel encoder signal acquisition interface, receiving position feedback signals

8. Isolation design of board signals to reduce electromagnetic interference in industrial sites

9. Panel status indicator light, providing intuitive feedback on operation and fault information

10. Support multi axis PID servo algorithm operation processing

11. Golden finger CPCI plug-in structure, convenient disassembly and maintenance of cabinet

12. Industrial grade PCB board, anti vibration and adaptable to automation equipment working conditions

13. Reserved jumper configuration, flexible modification of board working mode

14. Support real-time multitasking processing, synchronized control of motion and IO

15. Equipped with overcurrent and overvoltage hardware protection to enhance the lifespan of the board

Delta Tau 603625-102A UMAC-CPCI data system PCB, as the core board of UMAC-CPCI system, is used for multi axis motion control and data processing of high-end automation equipment.
