 Introduction

Alstom P120 B00M101 overcurrent protection relay

1. Implement three-phase overcurrent and overload fault detection and protection

2. Multi segment current protection setting, adjustable action threshold in stages

3. Panel button operation, on-site parameter configuration and fault viewing

4. LCD display window, real-time display of current measurement values

5. Support multiple protection features such as overcurrent reverse time limit and timed limit

6. Multi channel switch input and output, complete interlocking trip logic

7. Built in fault event recording, storing the timing of fault occurrence

8. Communication interface, capable of uploading data to the upper monitoring system

9. Equipped with self checking function and active alarm prompt for device abnormalities

10. Installation of rails/panels, flexible on-site installation of cabinets

11. Wide working voltage, AC/DC universal power input

12. Wide temperature working range, suitable for harsh working conditions in substations

13. EMC electromagnetic compatibility, resistant to strong electromagnetic field interference

14. Hardware circuit protection, capable of withstanding short-term high current surges

15. Adapt to the protection scenarios of power equipment such as feeders and motors

Alstom P120 B00M101 overcurrent protection relay, microcomputer protection device, used for overcurrent fault protection of distribution circuits and motor equipment.

Product imag
