Alstom VDG14AF9001ACH displacement relay

Alstom VDG14AF9001ACH displacement relay

 Introduction

Alstom VDG14AF9001ACH displacement relay

1. Monitor mechanical displacement and achieve position over limit protection output

2. Mechanical displacement detection triggers corresponding switch contact actions

3. Installation of rail rack, easy disassembly, debugging, and maintenance operation

4. Adjustable action threshold, suitable for different displacement protection ranges

5. Adequate contact capacity, directly driving the interlocking control circuit

6. Fast response speed, quick triggering of protection for abnormal displacement

7. Equipped with a mechanical reset structure, it is easy to recover after troubleshooting

8. Industrial shell protection, anti vibration and adaptable to on-site working conditions

9. Wide temperature working range, stable operation in high and low temperature environments

10. EMC electromagnetic protection, resistant to on-site electromagnetic interference

11. Stable mechanical structure with minimal drift during long-term operation

12. Intuitive status indication for easy on-site fault diagnosis

13. Compact structure, saving internal space of control cabinet

14. Multiple units can be combined to achieve multi-point displacement monitoring and protection

15. Adaptive transmission and power equipment safety interlocking system

Alstom VDG14AF9001ACH displacement relay is a displacement monitoring and protection component commonly used in transmission equipment and power plant mechanical position interlock protection circuits.

Product imag
