 Introduction

Alstom MAE00-14 Analog I/P Terminal Panel

1. 4-channel analog signal interface, processing on-site analog input signals

2. Rail mounted installation, easy to disassemble and replace cabinet

3. Clear terminal identification, convenient wiring and maintenance

4. Signal isolation design to reduce circuit signal crosstalk

5. Compatible with Alstom DCS control system, with good compatibility for docking

6. Industrial hardware structure, suitable for harsh working conditions in power plants

7. Signal conditioning and processing of voltage and current analog signals

8. Onboard power processing unit, stable signal circuit power supply

9. Wide temperature working range, stable operation in high and low temperature environments

10. EMC electromagnetic protection, resistant to on-site electromagnetic interference

11. Centralized transfer of on-site sensors and system card circuits

12. Compact size, saving installation space for control cabinets

13. Multiple blocks can be connected in parallel to expand the number of analog signal channels

14. Easy to locate faults and shorten on-site troubleshooting time

15. Meet the standards for the use of industrial control equipment in the power industry

Alstom MAE00-14 analog I/P terminal panel, analog signal conversion and conditioning unit, commonly used in industrial control systems of power plants.

Product imag
