DALSA AQUARIUS OR-X4C0-XPF00 acquisition card

DALSA AQUARIUS OR-X4C0-XPF00 acquisition card

 Introduction

DALSA AQUARIUS OR-X4C0-XPF00 acquisition card

1. PCI-E bus industrial image acquisition card, high-speed image data transmission

2. Support Camera Link interface, compatible with area array and line scan industrial cameras

3. Multi channel synchronous acquisition, multi camera synchronous triggering with precise timing

4. Onboard hardware cache effectively avoids image frame loss issues

5. Data processing offloading to reduce host CPU usage

6. Trigger signal input/output, compatible with external sensor devices

7. FPGA hardware architecture, strong real-time image processing and computing capabilities

8. Driver compatible with Windows and Linux systems, suitable for secondary development

9. Gold finger board structure, standard industrial control chassis slot installation

10. Anti interference circuit design, stable operation of workshop electromagnetic environment

11. Support PoCL camera power supply, simplify on-site wiring and cabling

12. Board status indicator light, quickly determine hardware working status

13. Adequate bandwidth to meet the requirements of high-resolution and high frame rate image acquisition

14. Long term continuous operation, suitable for 24-hour operation of machine vision production lines

15. Commonly used in semiconductor inspection and visual systems for appearance defect detection

The DALSA AQUARIUS OR-X4C0-XPF00 acquisition card is the core image acquisition hardware of machine vision inspection systems.

Product imag
