ASYST 9700-6209-01 power module

ASYST 9700-6209-01 power module

 Introduction

ASYST 9700-6209-01 power module

1. Dedicated power distribution unit for wafer transfer robots, with centralized distribution and output of multiple power sources

2. Stable output voltage and low ripple ensure smooth operation of the robotic arm servo

3. ASYST 9700-6209-01 Integrated Split Overcurrent and Short Circuit Independent Protection

4. Metal shielding shell effectively suppresses electromagnetic interference in clean workshops

5. Built in EMI filtering circuit to reduce the impact of power grid fluctuations

6. Excellent power conversion efficiency, controllable temperature rise during long-term full load operation

7. Support power status signal feedback for easy monitoring of faults in the main control system

8. Modular integrated structure, easy and efficient disassembly and replacement of the whole machine

9. ASYST 9700-6209-01 components undergo high-temperature aging screening

10. Split independent power supply design, single branch faults do not affect the entire machine

11. Equipped with power on slow start function to avoid damage to components caused by startup surge current

12. The terminal layout is neat and clear, making it convenient for on-site maintenance and circuit inspection

13. Industrial wide temperature design, suitable for continuous operation of semiconductor equipment

14. Seismic reinforcement structure to meet the vibration environment requirements of wafer handling equipment

15. Standardized installation dimensions to match ASM Epsilon equipment cabinets

The ASYST 9700-6209-01 power module serves as the core power distribution device for the wafer manipulator, ensuring continuous and reliable power supply for the transmission system.

Product imag
