XTRAMUS B-00-23L4GMPA2 Printed Circuit Board

XTRAMUS B-00-23L4GMPA2 Printed Circuit Board

 Introduction

XTRAMUS B-00-23L4GMPA2 Printed Circuit Board

1. B-00-23L4GMPA2 uses industrial grade board, with stable and durable structural strength

2. Accurate impedance control ensures stable transmission of high-speed communication signals

3. Optimize surface treatment process to enhance the welding reliability of B-00-23L4GMPA2

4. Partition wiring design effectively suppresses signal crosstalk between channels

5. The interlayer compression is tight, making it difficult to separate layers under long-term high and low temperature conditions

6. Excellent insulation performance, avoiding safety hazards such as leakage and short circuit

7. Low thermal expansion characteristics, not easily deformed under temperature changes

8. The specifications of the solder pads and positioning holes are unified, making it easy to replace and assemble the entire machine

9. B-00-23L4GMPA2 completes a complete set of conductivity and insulation factory testing

10. Adequate current carrying capacity, balancing signal transmission and power supply requirements

11. Moisture resistant and moisture resistant, suitable for the internal working environment of automation equipment

12. Follow the electromagnetic compatibility layout and weaken external electromagnetic interference

13. High density circuit layout, fully utilizing limited installation space

14. Reserved debugging pads for easy later testing and troubleshooting

15. Complies with the quality inspection standards for industrial control circuit boards

XTRAMUS B-00-23L4GMPA2 printed circuit board is used as the internal signal transmission substrate for communication modules
