NI PXle-1071 Embedded Controller

NI PXle-1071 Embedded Controller

 Introduction

NI PXIe-1071 Embedded Controller

1. The PXIe-1071 is equipped with a high-speed PXIe backplane, providing ample data transmission bandwidth

2. Support mixed slots, compatible with various functional modules of PXI and PXIe

3. Built in synchronous clock bus ensures precise timing synchronization of multiple modules

4. Optimization of chassis cooling structure, PXIe-1071 maintains stable temperature control during long-term operation

5. Modular plug-in architecture, convenient module disassembly, debugging, and replacement

6. Electromagnetic shielding shell, effectively suppressing external electromagnetic signal interference

7. Wide voltage power supply adaptation, continuous and stable operation under voltage fluctuation conditions

8. Equipped with a standard trigger bus to meet the requirements of automated testing linkage

9. Compact and lightweight, suitable for desktop and portable testing scenarios

10. PXIe-1071 supports LabVIEW software, with a low threshold for development and debugging

11. Multiple power protection circuits to avoid the risk of hardware damage caused by overload

12. Backplane signal isolation design reduces signal crosstalk between channels

13. Supports multiple communication protocols for easy integration with the upper control system

14. After long-term aging testing, the reliability of industrial testing scenarios is high

15. Standardized installation specifications, can be matched with racks to complete fixed assembly

The NI PXIe-1071 embedded controller is widely used in automation measurement, semiconductor testing equipment measurement and control systems

Product imag
