 Introduction

#DALSA HS-80-08K80 Scanning Camera

DALSA HS-80-08K80 is an industrial high-speed TDI line scan camera with high resolution and sensitivity, suitable for high-precision coil and panel detection.

1. Equipped with 8K high-definition pixels, the imaging details are clear

2. Maximum 68.6kHz line frequency, high scanning efficiency at high speed

3. Maximum data throughput of 640Mpix/s, fast transmission

4. Support bidirectional scanning and adapt to forward and reverse feeding conditions

5. Optional TDI/array dual working mode, easy to debug

6. 100x anti glare, suppresses overexposure caused by high light overflow

7. Built in flat field correction to eliminate color differences in imaging brightness and darkness

8. Exposure, gain, and bias parameters can all be programmed through software

9. 8-channel Tap output, paired with Full Camera Link interface

10. Ultra high sensitivity response, stable imaging in low light environments

11. The highest integration level is 96, and the sensitivity is flexible and adjustable

12. Equipped with self checking diagnosis and testing output, easy to troubleshoot faults

13. Operating at a wide temperature range of 0-50 ℃, with strong adaptability to the workshop environment

14. Compact and lightweight body, easy to install inside the device

15. Factory complete imaging inspection, stable imaging consistency

In summary, the DALSA HS-80-08K80 scanning camera combines high speed, high resolution, and strong anti-interference capabilities, which can meet various high-precision industrial visual scanning and detection needs.

Product imag
