 Introduction

ETEL DSCDL332-131-000 linear position controller is compatible with semiconductor precision linear motor dual axis control, with nanometer level positioning accuracy and stable bus synchronization.

1. Dual axis independent drive, capable of synchronously controlling the motion axes of two sets of linear motors

2. Compatible with EnDat, TTL, 1Vpp multi class encoders, high subdivision interpolation accuracy

3. Turbo TEL Bus high-speed bus, multi module daisy chain networking with strong synchronization

4. Built in tooth slot and friction compensation algorithm to suppress linear axis shaking

5. 20kHz closed-loop control cycle, short start stop setting time

6. Each axis comes with isolated digital IO, linked limit and sensor signals

7. Analog input channel, capable of collecting pressure and displacement auxiliary signals

8. Multiple hardware protections, automatic shutdown and locking for overcurrent, overvoltage, and overheating

9. Support dual encoder feedback and real-time correction with gantry architecture

10. Onboard large capacity program storage, capable of writing 4096 segments of motion programs on a single axis

11. 6U standard CPCI board, easy to plug and disassemble industrial control chassis

12. Industrial wide temperature design, stable operation of high and low temperature chamber conditions

13. Hardware filtering isolation to resist plasma and electromagnetic interference

14. Equipped with ETEL Tools debugging software, parameter calibration and diagnosis are simple

15. Strengthen internal wiring to adapt to long-term vibration and continuous operation of production lines

Overall, the ETEL DSCDL332-131-000 linear position controller has high accuracy and complete expansion, making it the core control component for linear motion in semiconductor wafer platforms and precision testing equipment.

Product imag
