IPG ELM-30-1550 Photon Laser

IPG ELM-30-1550 Photon Laser

 Introduction

Product Features of IPG ELM-30-1550 Photon Laser

Introduction: IPG ELM-30-1550 is an OEM 30W erbium-doped single-mode continuous fiber laser from IPG, with a 1550nm eye safe infrared band, suitable for optical detection, communication, medical and precision processing equipment light source units.

Standard 1550nm output wavelength, wavelength accuracy ± 1nm, suitable for infrared optical detection scenarios

Rated 30W continuous single-mode output, power adjustable range of 1% -100%, linear stability adjustment

Diffraction limit beam quality, uniform spot, low beam transmission loss

Narrow linewidth spectral output, long-term power fluctuation ≤ 0.5%, excellent output consistency

All fiber integrated structure, no spatial optical path, anti vibration and less likely to cause optical path deviation

Air cooled cooling design, no need for water cooling, simplifies cabinet wiring

Compact OEM modular body, rail installation saves internal space of equipment

Support 2kHz direct optical modulation, can be synchronously triggered with visual and sensing devices

Optional built-in optical isolator to prevent reflected light from damaging the internal pump chip

Metal shielding shell, resistant to electromagnetic and RF signal interference in the workshop

Built in real-time temperature monitoring, automatic power reduction protection for laser over temperature

Multiple circuit protection, with self-locking function for overcurrent, overvoltage, and short-circuit faults

FC/APC standard fiber optic output connector, easy to disassemble and replace optical path operation

Industrial grade pump source components, capable of 24-hour uninterrupted stable operation

Equipped with a communication serial port, it can be connected to the main control of the whole machine to achieve remote power control

Conclusion: IPG ELM-30-1550 is a core laser light source accessory for infrared optical measurement, plastic welding, and optical communication equipment, with stable beam and compact packaging.

Product imag
