BOBST 0704169901 747-CL Drive Control Board

BOBST 0704169901 747-CL Drive Control Board

Product Details Introduction

BOBST 0704169901 (747-CL) drive control board

BOBST 0704169901/747-CL is a dedicated servo drive board for the Bobst 707 series of paste boxes/die-cutting, which controls the power output of the paper feeding motor and pneumatic actuators.

1. Multiple sets of power connection terminals, directly connected to workstation servo motors and solenoid valve loads

2. The 747-CL is equipped with strong and weak electrical optoelectronic isolation to isolate workshop power grid harmonic interference

3. The whole board is coated with a three proof solder mask to resist ink dust and workshop condensation corrosion

4. Gold plated card slot with gold fingers, the device is not easily oxidized due to high-frequency vibration and virtual connection

5. Integrated overcurrent, overvoltage, and overheating triple protection, automatic shutdown and locking in case of load failure

6. Partition power routing to suppress electromagnetic crosstalk in high-power circuits

7. Original industrial power components, stable continuous operation over a wide temperature range of -20 ℃~70 ℃

8. Multi channel power supply and fault indicator light, quickly locate the points of phase loss and overload faults

9. Standard cage installation size, in-situ plug and replace without changing wiring

10. Each drive channel has an independent power circuit, and if there is a single load fault, the entire board will shut down

11. Onboard storage chip, storing original factory parameters of motor speed and travel

12. Thickened fiberglass PCB substrate, resistant to equipment start stop impact and mechanical vibration

13. Optimize the power circuit and ensure reasonable temperature rise control during long-term full load operation

14. 704 bus dedicated communication protocol, compatible with 704 and 701 series main control cards

15. BOBST 0704169901 is compatible with the entire series of Bosch 707 high-speed paste box and automatic die-cutting equipment

Conclusion: The 747-CL serves as the core power drive for the entire machine, precisely regulating the power operation of the paper feeding, folding, and waste cleaning stations.
