BOBST 704-1123-03 is a 704 series bus IO interface board, responsible for on-site point signal acquisition and main control communication transfer of paste box die-cutting equipment.

1. Multi way wiring terminal, docking station photoelectric, limit switch and solenoid valve components

2. 704-1123-03 has a built-in photoelectric isolation circuit to block the interference of workshop power grid clutter

3. The board surface is coated with three anti solder mask coatings, which resist ink dust, environmental condensation and corrosion

4. Gold plated finger slot, device continuously vibrates and is not easily oxidized, virtual connection

5. Integrated overcurrent and short circuit protection, automatic locking protection for external line faults

6. Layered and partitioned wiring effectively reduces electromagnetic crosstalk interference in power lines

7. Original industrial grade components, stable operation over a wide temperature range of -20 ℃~70 ℃

8. Channel status indicator light, quickly locate single point signal faults

9. Standard card cage size, in situ plug and replace without changing the circuit

10. Each channel has independent circuits, and a single fault will not cause the entire board to shut down

11. Onboard storage components, storing point configuration and overall communication parameters

12. Thickened seismic resistant PCB substrate, suitable for high-speed start stop vibration conditions of equipment

13. Optimize low-power circuits and achieve low temperature rise during long-term mass production operation

14. Original factory exclusive communication protocol, compatible with all 701 and 704 series supporting boards

15. BOBST 704-1123-03 is compatible with the Bobst 707 series high-speed paste box and die-cutting equipment

Conclusion: 704-1123-03 serves as the signal hub for the entire machine, ensuring stable operation of the paper feeding, detection, and pneumatic workstations.
