BOBST 701-1528-01 power board

BOBST 701-1528-01 power board

Product Details Introduction

BOBST 701-1528-01 is a dedicated multi-channel output DC/DC power board for the 701 control rack, which supplies power to the DSP, I/O, and communication boards of the 701 series die-cutting/pasting box machine.

Original Factory Number: 701-1528-01 (701 Platform Standard Power Board)

Compatible models: MASTERFOLD glue box machine, EXPERTCUT die-cutting machine, LB701-UV printing machine and other 701 rack equipment

Input voltage: 24VDC ± 20% (industry standard)

Output configuration (multi-channel isolation)

+ 5V@8A (Core Logic/DSP Power Supply)

+ 12V@4A (Relay/Sensor/Fan)

-12V@1.5A (Analog circuit/operational amplifier)

+ 24V@3A (I/O module reserved)

Rated power: about 120W, efficiency 88%~92%

Electrical isolation: 1500VDC isolation between input/output, resistant to common mode interference

Protection mechanism: overvoltage, undervoltage, overcurrent, short circuit, over temperature (self recovery)

Status indication: PWR (normal), FLT (faulty) dual color LED diagnosis

Heat dissipation design: metal base plate+natural convection, wide temperature range -10 ℃~+60 ℃

Anti interference: EMI filtering, surge suppression, differential signal protection

Industrial protection: PCB three proof coating (moisture-proof/dustproof/anti ink)

Installation interface: 701 rack standard slot, gold-plated gold finger seismic resistant

Replacement feature: Same number direct insertion replacement, no debugging, automatic parameter matching

Supporting board: compatible with 0701218204 (DSP board), 701-1957-01, etc

Product imag
