Product Details Introduction

1、 Product Overview

Model: 6679-07-011

Internal identification: BG03 power board

Type: High Voltage (HV) power supply board, used in Magentek/Power One series equipment

2、 Technical features and parameters

Purpose: This power board provides high-voltage DC or pulse power for lamps, electrical control equipment, or related high-voltage modules, commonly used in industrial electric drives, lighting dimmers, or specific driving application scenarios.

High voltage level: The rated maximum voltage is about 4 kV, suitable for driving 70W lamps or high voltage loads

Packaging form: Installed on a metal base plate for easy fixation and heat dissipation

Safety certification: Complies with UL 94V-0 flame retardant standard (marked RL CP5)

Manufacturer: Magnetek/Power One series boards

3、 Typical application areas

High voltage lighting equipment

Voltage ignition and stabilization for seat discharge lamps, fluorescent lamp ballasts, or specific industrial light sources

Provide stable high voltage output when driving 70W lamp equipment

Industrial electronic control system

Applied in Magentek control power supply, providing isolated high voltage source for control units or motherboard modules

Support power supply requirements for dimming panels, driver modules, or high-voltage testing equipment

Replacement and maintenance purposes

Often provided as inventory spare parts for equipment maintenance or replacement of faulty power boards

New or second-hand purchasing channels can be seen in the market, which can be used by magnetic flux and maintenance service providers

Product imag
