MAGNETEK GPD505V-B011 AC Driver

Magnetek 6679-07-011 BG03 power board

Product Details Introduction

1、 Product Overview

Model: GPD505V-B011

Series: GPD505V Series Universal Variable Frequency Drive

Input voltage: three-phase 380-480V AC

Output current: approximately 11A

Rated power: 7.5 HP (approximately 5.6 kW)

Control mode: V/f control (voltage/frequency ratio control)

Applicable motor: three-phase induction motor

2、 Product Features

Mature and stable V/f control technology

Suitable for variable torque loads such as fans and pumps

Provide stable low-speed output capability

Strong overload capacity

150% current for 1 minute

Adapt to scenarios with significant load fluctuations

Multi functional digital/analog input/output interface

Multi channel programmable digital input: supports start stop, forward and reverse rotation, fault reset, etc

Analog input supports 0-10V or 4-20mA: used for frequency or speed control

Relay output can be used for operation indication, fault alarm, etc

A comprehensive protection mechanism

Built in multiple protections such as overvoltage, overcurrent, undervoltage, overheating, and short circuit

Fault code display facilitates quick on-site diagnosis

Compact design, easy to integrate

The module has a small volume and light weight, making it easy to install inside the control cabinet

Air cooled design, suitable for enclosed or well ventilated electrical control boxes

Convenient maintenance

Simple parameter settings, supporting panel debugging or copying

Easy to replace and repair, suitable for long-term use in industrial environments

Product imag
