Gasonics A98-014-01 Display Decoder

Gasonics A98-014-01 Display Decoder

Product Details Introduction

1、 Product Overview

Gasonics A98-014-01 is a Display Decoder Module specifically designed for Gasonics plasma equipment. Its main function is to parse and convert data signals from autonomous control systems or interface panels into graphic or character information, and output it in a visual manner on the front-end display or interface terminal. This module is typically located in the human-machine interface (HMI) system of the device, responsible for bridging digital signals to visual interface information.

2、 Application Fields

1. Plasma processing equipment (such as Aura/PEP series)

Decoding process flow status, temperature/pressure sensor data, timing information, etc. and outputting them to the main display screen;

Support the conversion of text and graphics such as alarms, operating status, and system prompts.

2. Linkage between control panel and LCD screen

Connect the main control board to the touch screen or LCD screen to perform information driven tasks;

Parse interface command signals and drive graphic/character output.

3. System debugging and status monitoring module

Used for debugging engineers to visually monitor the status of underlying signals;

Support intuitive display of process logs or error codes on the screen.

Product imag
