Gasonics 90-2609 Display Decoder

Gasonics 90-2609 Display Decoder

Product Details Introduction

Product Name: Gasonics 90-2609 Display Decoder

Component type: Digital Display Decoder Module

Main function: Convert the digital signals of the device control system into corresponding display driving signals, which are used to drive display devices such as digital tubes and LED displays, and achieve visualization of status information

1、 Equipment status display interface

The 90-2609 display decoder is commonly used in the operation panel or control cabinet of Gasonics plasma equipment, responsible for displaying process parameters, equipment status, alarm codes, etc.

Typical display content:

Countdown of processing time

Process step number

Alarm and fault codes

System operation status indication

2、 Digital signal and display driver conversion

This module will decode binary, BCD or other encoded signals from the main control board, convert them into corresponding driving level signals, and control multi bit digital tubes or LED display units.

Interface type:

Input: Standard digital encoded signal (such as BCD, binary)

Output: Segment selection and bit selection drive signals

3、 Integrated application scenarios

As a part of the human-machine interface (HMI) of the device, the display decoder helps operators intuitively understand the operating status and parameters of the device, and helps to quickly determine the working status and cause of faults of the device.

Applicable module combinations:

Operation control panel (such as Gasonics A95-108-02)

Main control logic board (such as ABX-88919-41)

Alarm and indication module
