3BHE039203R0101 GVC736CE101 thyristor module

3BHE039203R0101 GVC736CE101 thyristor module

Product Details Introduction

1、 Product Overview

GVC736CE101 (ABB order number: 3BHE039203R0101) is a high-power industrial grade thyristor module (Thyristor Module), which is a key control device in ABB power electronic component systems. This module is mainly used in the fields of medium and high voltage variable frequency drive, grid commutation, power transmission, etc., for functions such as power control, commutation, and rectification. It is one of the core components of ABB medium voltage drive systems (such as ACS6000/ACS800MV, etc.).

2、 Technical parameters (typical values)

Project parameter values or descriptions

Model GVC736CE101

Order number 3BHE039203R0101

Type: thyristor module/thyristor component

Voltage level (V_drm) 4500V typical (slightly varying depending on specifications)

On state average current (I_{T (AV)}) 2500A~3000A typical

Control mode: phase controlled triggering or rectification/inverter control

Packaging form: Industrial grade module packaging with cooling interface

Application system ABB medium voltage drive, power transmission, power quality equipment

Cooling method: Water cooling/forced air cooling

3、 Application scenarios

1. ABB medium voltage frequency converter system (ACS6000/ACS800MV)

As the core rectifier/converter module of the main power section;

Suitable for speed control and energy-saving operation of high-power industrial motors;

Industries: Petrochemicals, Cement, Metallurgy, Mining, etc.

2. High voltage rectification system

High voltage DC rectifiers used in the metallurgical and chemical industries;

For example: electrolytic aluminum, electroplating, electric arc furnace power supply system;

Provide stable high current DC output.

3. Grid converter station/HVDC system

Converter valve module for AC/DC power conversion stations;

Ensure flexible switching of voltage and current directions in the power grid;

Has extremely high electrical reliability requirements.

4. Excitation system for large synchronous motors

Used to provide adjustable excitation current to control the operation of synchronous motors;

Commonly seen in power plant turbine and water turbine drive systems.

5. FACTS power quality control device

Such as SVC (Static Var Compensation) system or STATCOM system;

Provide fast dynamic response, balance voltage fluctuations, and suppress harmonics.
