TEL Tokyo Electron 3208-000070-13 Circuit Board

TEL Tokyo Electron 3208-000070-13 Circuit Board

Product Details Introduction

1、 Basic Information

Product model: 3208-000070-13

Product Name: Circuit Board

Manufacturer: TEL - Tokyo Electron Limited

Version number: Version 13 ("-13" indicates the specific version or revision number of the circuit board)

Product Category: Control/Interface PCB Board (Speculative)

2、 Function and Function (Based on TEL Naming Rules and Usage Scenarios)

This model of circuit board may have the following functional characteristics:

Functional category description

System signal processing is used to receive, forward, or amplify commands or feedback signals from the upper control system.

Control interface bridging serves as a relay or connector board between multiple modules, used to transmit control signals.

The communication function interacts with the main control board of the device to exchange data and execute logical control commands (possibly using a dedicated communication protocol).

The actuator connection board connects external devices such as solenoid valves, motors, sensors, etc., providing power and signal interfaces.

3、 Typical application device fields (speculated)

According to Tokyo Electron's part numbering system, the 3208 series circuit boards are commonly used for control and signal processing functions in the following systems:

ACT series lithography pre-processing equipment (Coater/Developer)

Used for coating and developing modules, pump control, pressure monitoring systems, etc.

Tactras series etching equipment

Control subsystems such as vacuum valve, chamber temperature, and gas channel switching.

Unity/Trias series CVD system

Responsible for temperature control module, deposition gas channel switch, heating element control, etc.

Clean Track series equipment

Signal distribution and feedback control, including motor control, electromagnetic relays, sensor signal acquisition, etc.

Product imag
