Novellus Systems 03-056746-00 Controller Module is a core control unit used in Novellus semiconductor equipment, commonly used for real-time monitoring, logic processing, and signal coordination of equipment process flow. This module may be an embedded control module customized for a certain generation of Novellus CVD (chemical vapor deposition) or PVD (metal deposition) equipment.

1、 Basic Information

Product Name: Controller Module

Product model: 03-056746-00

Manufacturer: Novellus Systems Inc. (now part of Lam Research)

Function classification: Embedded control board/processor module

Application scope: Used for device logic control, process parameter adjustment, I/O interface management, etc

2、 Core functions

Function module description

Processing logic controls the execution of key logic instructions such as device startup, gas flow, temperature control, vacuum flow, etc

I/O interface communication management and input/output signal transmission between peripheral devices (sensors, actuators, valves, power boards, etc.)

Real time data processing and collection of process data (temperature, pressure, flow rate, etc.) for local processing and uploading

Fault monitoring and protection can monitor the operating status, automatically identify errors or alarms, and link emergency shutdown or parameter adjustment

The bus communication capability communicates with the system main control or other control modules through RS232, CAN, or dedicated buses (depending on the device platform)

3、 Possible hardware structure (typical Novellus control module configuration)

CPU or DSP main control chip

FPGA/CPLD (for high-speed data processing)

EEPROM/Flash storage process parameters

Multi channel ADC/DAC

Isolation type digital input/output interface

Power management unit (± 15V or 5VDC input)

Onboard diagnostic LED, testing interface, etc
