Novellus Systems 02-052474-00 DC terminal block
- Goods status： new/used
- Delivery date: stock
- The quality assurance period： 365 days
- Phone/WhatsApp/WeChat：+86 15270269218
- Email：stodcdcs@gmail.com
- Tags：
- Get the latest price：Click to consult
Novellus Systems 02-052474-00 DC terminal block
Product Details Introduction
Novellus Systems 02-052474-00 DC Wiring Board is a module used for power distribution or signal wiring functions within Novellus semiconductor manufacturing equipment. It is mainly used in the system for the organization, distribution, and interface connection of DC power supply lines, and is one of the indispensable basic components in equipment electrical systems.
1、 Basic Information
Product Name: DC Wiring Board
Model: 02-052474-00
Manufacturer: Novellus Systems Inc. (merged into Lam Research)
Application areas: Power distribution, signal wiring, and bridging of semiconductor devices
Module Type: Backboard/Terminal Block
2、 Function Description
Functional category description
DC power distribution provides multiple power output ports, distributing the main power supply (such as 24V, 48V, etc.) to various sub modules of the equipment (such as sensors, actuators, solenoid valves, control boards, etc.)
Signal sorting distributes low-voltage signals from the main control or control module to each executing component through a unified wiring method
Grounding/shielding management provides a good grounding or shielding wire connection channel to reduce electromagnetic interference
Some versions of safety isolation may integrate basic protection measures such as overcurrent protection and fuse holders
3、 Typical application locations
This wiring board may be installed in the following devices or areas:
Inside the power distribution cabinet of the Concept series PECVD/SACVD/HDCPVD systems
Rear wiring area of electrical control box or equipment
Concentrated point of I/O wiring near the process chamber
Used in conjunction with DC power supply or relay/fuse modules
Product imag
