Novellus Systems 03-132056-00 Sensor Board
Product Details Introduction
The Novellus Systems 03-132056-00 Sensor Board is an electronic control board used in Novellus semiconductor process equipment, specifically responsible for the acquisition, conversion, and transmission of sensor signals. It is typically used as a key detection unit in the system and works in conjunction with the main control system to achieve precise control.
1、 Basic Information
Product Name: Sensor Board
Model: 03-132056-00
Manufacturer: Novellus Systems Inc. (now a subsidiary of Lam Research)
Type: Process control dedicated sensor interface board
Installation location: commonly found in equipment chambers, under platforms, or within the main control framework
2、 Main functions
signal acquisition
Receive input signals from multiple analog or digital sensors, such as temperature, pressure, position, flow rate, etc.
Signal conditioning/conversion
Provide necessary signal amplification, filtering, isolation, level conversion and other processing functions.
data transmission
Send the processed sensor data to the control unit or upper computer to achieve real-time feedback control.
Multi channel support
Can connect multiple sensors, support multi-point synchronous monitoring, and improve control accuracy.
Product imag
