Product Details Introduction

PHOENIX CONTACT QUINT-PS-100-240AC/24DC/40 is a high reliability, industrial grade power supply module belonging to the QUINT POWER series, designed specifically for harsh industrial applications, with high power density, redundant power supply capability, and multiple protection mechanisms.

Basic information

Product model: QUINT-PS-100-240AC/24DC/40

Order number: 2938879

Manufacturer: PHOENIX CONTACT

Product type: Switching power supply, DIN rail installation

Main technical parameters

input parameter

Input voltage range: 100-240 V AC (acceptable 85-264 V AC)

Simultaneously supporting 90-350 V DC input

Power efficiency: up to 94%

Start surge current:<15 A

Output parameters

Output voltage: 24 V DC (adjustable range: 18-29.5 V)

Output current: 40 A continuous

Power: 960 W

Support Power Boost mode: Sustainable output of 45 A current

Ripple voltage:<30 mVpp

Fast dynamic response, suitable for starting heavy load devices

Protection function

Short circuit protection (electronic automatic recovery)

Output overvoltage protection (maximum<35 V)

Undervoltage monitoring and alarm function

Thermal protection (automatic derating or shutdown when temperature rise is too high)

Product imag
