Product Details Introduction

Technical Description of GE 193X703ADG02 Relay Board

Product model: 193X703ADG02

Product Name: Relay Board

Manufacturer: General Electric (GE)

Product Series: 193X Control Card Series

Typical applications: Drive control system, state switching, signal relay and alarm interlock control

1、 Product Features

193X703ADG02 is a multi-channel relay control board in the GE 193X series, mainly used for:

Receive logic control signals and control multiple relay actions;

Realize remote control, interlocking protection, and fault isolation of electrical equipment;

Collaborate with other control boards (such as AAG, ACG, BAG, etc.) to complete the complete control logic.

2、 Typical technical parameters

Parameter project description

Control input digital control signal (from controller or logic circuit)

Output interface dry contact relay output (usually normally open NO or normally closed NC)

The control voltage is usually 24V DC or ± 15V DC (depending on the system configuration)

Installation method: Plug in gold finger connection, compatible with 193X main control rack

Multiple small relays, resistors, capacitors, transistors, freewheeling diodes, etc. are configured on the board

Size specification standard GE 193X board size (with a gripper at the front end for easy insertion and removal)

3、 Actual application scenarios

Early GE DC drive control systems (such as DC2000 or similar systems);

Turbine automation control system (Speedtronic Mark series);

Logic switching module or remote relay control in industrial control cabinets;

Used for motor start stop, valve switch, fault output alarm and other action logic.
