Product Details Introduction

GE 193X703ADG04 Relay Module Technical Data

Product model: 193X703ADG04

Product Name: Relay Module

Manufacturer: General Electric (GE)

Product series: 193X series control board

Application areas: Industrial automation, DC speed control system, generator control, heavy-duty drive control system

1、 Module function overview

193X703ADG04 is a module used in the GE 193X control system for electrical control signal switching and relay execution. It achieves the following functions by receiving signals from the upper level control logic board, controlling the relay to close or disconnect:

Control the start and stop of high-power equipment;

Implement fault locking or interlocking logic;

Transmitting status signals to other modules;

Complete the device control state transition.

2、 Main technical parameters

Parameter item description

Control signal input: Multiple digital control signals (usually TTL/24V DC signals)

Multiple relay dry contact outputs (normally open NO or normally closed NC)

Power supply voltage ± 15V DC or 24V DC (depending on the system)

Card structure plug-in module, with a gripper at the front end and a gold finger connection to the 193X main frame at the back end

Relay type: Small electromagnetic relay (board mounted, reliable operation)

The number of signal channels is usually 4-8 (depending on the sub model design)

3、 Typical application scenarios

GE DC2000 DC Speed Control Drive System;

Speedtronic Mark I~V turbine control system;

Drive control cabinets for petrochemical, steel, and power industries;

Equipment interlocking control, remote operation command execution;

Used in conjunction with other modules such as 193X703ACG, AAG, BAG series boards.
