Product Details Introduction

GE 193X703ADG01 Relay Board Technical Description

Product model: 193X703ADG01

Product Name: Relay Board

Manufacturer: General Electric (GE)

Product Series: 193X Control Module Series

Typical application: Control logic execution for signal switching, fault interlocking, state transition, etc. in industrial control systems

1、 Function Description

193X703ADG01 is a multi relay output control board specifically designed for industrial automation and drive systems. Its main responsibility is to switch multiple relays based on control logic to achieve:

Remote start stop of electrical equipment;

Alarm signal or interlock logic execution;

Relay output of control instructions;

Feedback the action status to the upper level controller.

2、 Technical parameters (typical)

Project Content Description

Control input digital control signal (from logic board or central controller)

Output method: Multi channel relay dry contact output (normally open/normally closed)

The driving voltage is usually 24VDC or ± 15VDC (depending on the system)

The number of relays is 4-8 (depending on the specific configuration of the sub model)

Installation method: Insert the card and connect it to the 193X backplane with a gold finger

On board components such as small relays, transistors, diodes, current limiting resistors, etc

Size specification standard 193X board size, with front-end gripper

3、 Typical application scenarios

GE DC drive system (such as DC2000);

Mark I~Mark V control system;

Early turbine control and pump station control systems;

Industrial motors, valves, and relay control components;

Used in conjunction with statistical boards (such as ACG04) and interface boards (such as AAG02).

Product imag
