IS200FHVBG1A High Voltage Input Board
- Goods status： new/used
- Delivery date: stock
- The quality assurance period： 365 days
- Phone/WhatsApp/WeChat：+86 15270269218
- Email：stodcdcs@gmail.com
- Tags：IS200FHVBG1A
- Get the latest price：Click to consult
IS200FHVBG1A High Voltage Input Board
Product Details Introduction
IS200FHVBG1A High Voltage Input Board
product overview
IS200FHVBG1A is a high-voltage input board designed by GE General Electric for the LS2100 series static starting system. Its main function is to receive control signals and convert them into gate signals to drive thyristors. It also has the ability to detect, protect, and feedback input high voltage, and is a key high-voltage interface control component in the system
Core functions
The high-voltage input voltage guarantee system in the high-voltage input monitoring system operates within the safe voltage range
The gate signal drives the reception of trigger signals from the main control system to generate reliable gate pulse drives for SCR thyristor conduction
Feedback the voltage, current, and gate status to the higher-level control board for system protection and closed-loop control
Fault indication detection gate pole fault and transmission to FGPA or other main control logic modules through signal interface
Technical Parameter
The adaptation system is the LS2100 series
Typical application voltage level is medium voltage three-phase AC system
The working temperature range is minus 40 to 70 degrees Celsius
The board size is sixteen by twelve by sixteen centimeters
The weight is about 0.8 kilograms
Support multi-channel gate triggering and signal feedback
Capable of basic protective functions and suitable for industrial environments
Application scenarios
Mainly used for SCR thyristor trigger control in GE static excitation system
Start up and excitation control system for gas and steam turbines
Large industrial motor starting and power conversion system
High voltage interface and protection board in power electronic converter system
Product imag
