IS200LSGIH1A interface card
- Goods status： new/used
- Delivery date: stock
- The quality assurance period： 365 days
- Phone/WhatsApp/WeChat：+86 15270269218
- Email：stodcdcs@gmail.com
- Tags：IS200LSGIH1A
- Get the latest price：Click to consult
IS200LSGIH1A interface card
Product Details Introduction
IS200LSGIH1A interface card
product description
IS200LSGIH1A is a universal interface board developed by General Electric for its Mark VI or LS2100 control system. It is mainly responsible for signal interaction between the control system and external execution components. This module is usually used as a bridge for converting gate pulse signals and status signals, and is an important communication component for achieving closed-loop control in rectification systems
major function
Signal relay converts the low-voltage control signal of the controller into a standard logic signal for driving power components
Gate synchronization forwards the pulse timing of the main control board to multiple power modules to ensure synchronous operation of multiple bridge arms
State sampling collects the operating status signals of external actuators or power devices and returns them to the main control for status judgment
The communication interface provides high-speed digital communication interfaces with anti-interference capabilities to other parts of the system
Technical Parameter
Board type communication and control interface board
Typical application system Mark VI or LS2100
Installation method: The plug-in card module is installed inside the control rack
The working voltage is generally supplied with DC five volts or twelve volts
Working temperature range: minus 20 to 70 degrees Celsius
Typical dimensions are 30 centimeters by 20 centimeters
Weighing approximately 0.6 kilograms
Number of signal channels, multiple isolated channels supporting parallel transmission of multiple signal inputs and outputs
Connection method: Multi pin connector supports standard GE system connection bus
Application scenarios
Applied to GE Mark VI and LS2100 control systems
Used to control the synchronization of SCR gate triggering in high-voltage power supply systems
Can be used for modular power system interface of rectifier cabinet in turbine control system
Suitable for large-scale variable frequency control systems of power plant generator sets
Product imag
