IS200FGPAG1A amplifier module

IS200FGPAG1A amplifier module

Product Details Introduction

IS200FGPAG1A amplifier module

product overview

IS200FGPAG1A is an amplifier module designed by General Electric for the LS2100 series static starting system. It is mainly used to drive the gate signal of the thyristor and monitor its status to ensure the stable operation of the power system during the starting phase

Core functions

One control gate trigger

The module receives the gate signal from the main control board and amplifies it to drive high-voltage thyristor devices

Two state feedback monitoring

The module provides real-time feedback on the conduction status and operating voltage value of the SCR to assist the control system in determining the switch status and fault conditions

Three power supply voltage conversion

Transform the input power supply into low-voltage DC power suitable for internal circuits for control and signal processing

Four system collaborative control

Collaborate with multiple sub boards in the LS2100 control platform to achieve complete startup control logic

Technical Parameter

The compatible systems are LS2100 and LS2100e

The working voltage level includes 2300V three-phase or 4160V and 6600V systems

Supports synchronous operation of up to six bridge arm structures

Typically installed inside the bridge cabinet and connected to the main control board through busbars and signal lines

The standard operating temperature range is from minus 20 degrees Celsius to 70 degrees Celsius

The weight of the module is approximately 0.9 kilograms

The module size is 61 centimeters by 51 centimeters by 51 centimeters

Application scenarios

Suitable for heavy-duty gas turbine static starting system

High voltage and high-power motor drive system

Variable frequency starting control system for industrial power plants

In situations where logic control and status feedback are carried out in conjunction with the SCR drive module
