ASSOCIATED RESEARCH 7564SA analyzer

ASSOCIATED RESEARCH 7564SA analyzer

 Introduction

The ASSOCIATED RESEARCH 7564SA analyzer is a four in one electrical safety comprehensive testing instrument that supports full range testing of withstand voltage, insulation, grounding, and conductivity

Equipped with QuadCheck four line measurement technology, the test data has high accuracy

2. Compatible with AC/DC withstand voltage, insulation, and grounding Class IV standard tests

3 output voltage adjustable AC up to 5kV DC up to 6kV

4 built-in arc detection function to quickly capture discharge faults and hidden dangers

5 can store 50 sets of test programs, each supporting an eight step process

The parameter readings on the 6-row LCD display screen are intuitive, clear, and easy to view

7 supports GPIB and PLC remote communication to adapt to automated production lines

8. Voltage load stabilization output fluctuation controlled within 1%

9. Comes with a graded password lock to prevent parameter errors and ensure testing standards

10 integrated EMC filtering circuits to avoid external electromagnetic signal interference

11 overcurrent short circuit high voltage self-locking multiple protections ensure operational safety

12 broadband input compatible with 47 to 63Hz industrial general power supply grid

13 standard rack mounted structure cabinet with easy installation and disassembly

14 current voltage segmented adjustable electronic medical home appliance detection

15. The whole machine runs stably and is suitable for long-term continuous testing operations on the production line

The testing function of the ASSOCIATED RESEARCH 7564SA analyzer is comprehensive and accurate, meeting the safety and compliance testing needs of various electrical products

Product imag
