Mitsubishi BC386A664G51 J3-P872 servo drive substrate

Mitsubishi BC386A664G51 J3-P872 servo drive substrate

Product Introduction

The Mitsubishi BC386A664G51 J3-P872 servo drive substrate belongs to the main control board inside the MR-J3 servo amplifier, responsible for current loop operation, encoder signal reading, and upper level motion command analysis. It is suitable for various precision automation axis control scenarios and has the following application areas:

1. SMT high-speed surface mount machine feed drive unit

2. PCB automatic board splitting machine motion control system

3. Servo control module for lithium battery winding machine

4. Precision CNC engraving and milling machine axis control substrate

5. Automatic optical detection equipment displacement platform

6. High speed sorting equipment for electronic components

7. Fully automatic dispensing and coating equipment

8. Printing equipment color matching servo mechanism

9. Connector press fit automatic assembly

10. Longmen truss transplanting robot arm

11. FPC soft board cutting equipment

12. Laser microfabrication equipment driver unit

13. Transplanting mechanism for chip testing machine

14. Multi axis synchronous control of packaging equipment

15. Laboratory precision positioning test bench

Mitsubishi BC386A664G51 J3-P872 servo drive substrate has fast response speed, stable current control, supports SSCNET III high-speed bus, and can achieve high-precision position, speed, and torque control under continuous high load conditions

Product imag
