MAZAK D70UB003951 relay unit

MAZAK D70UB003951 relay unit

 Introduction

MAZAK D70UB003951 relay unit

Product Features

Mazak CNC machine tool dedicated relay unit has high signal matching without modifying the circuit

Integrating multiple sets of relay contacts can synchronously control multiple action outputs of the machine tool

One glance identification and maintenance of onboard status indicator light fault channel saves time

Plug in interface design, easy on-site replacement, reduces machine downtime

Industrial grade relay components have long-term stable operation against cutting oil mist and workshop vibration

Product Specifications

Model MAZAK D70UB003951

Suitable for machine tool DC 24V standard power supply

Output point of multi-channel relay switch

Adapt to the signal logic of Mazak MAZATROL system

Standard card installation structure for electrical control cabinet

Application Areas

Action Circuit Control of Mazak Machining Center Machine Tool

Switching of start and stop signals for CNC lathe tool magazine

Machine tool lubrication cooling pump relay drive

On/off control of safety door interlock signal

Transfer of point signal for spindle auxiliary equipment

MAZAK D70UB003951 relay unit is a specialized relay component for Mazak CNC equipment, ensuring reliable execution of various auxiliary actions of the machine tool

Product imag
