BYSTRONIC E715-5-Q Control Board

BYSTRONIC E715-5-Q Control Board

 Introduction

BYSTRONIC E715-5-Q Control Board

Product Features

The dedicated control board for Baichao laser equipment has high signal acquisition accuracy and is compatible with the original factory system

The onboard gain offset adjustable potentiometer can directly calibrate the signal on site

The jumper switch configuration is flexible and can switch modes without changing the circuit on the board

Industrial grade PCB boards can withstand the effects of workshop dust and equipment vibration

Standard card installation structure disassembly and replacement quickly reduces downtime

Product Specifications

Model BYSTRONIC E715-5-Q

Adapt to the internal DC power supply of Baichao machine tools

Support analog signal acquisition and amplification processing

On board adjustable gain and offset calibration circuit

Support jumper for functional mode selection

Application Areas

Baichao laser cutting machine position signal processing unit

Servo feedback signal control of CNC bending machine

Replacement parts for motion control board of sheet metal laser processing equipment

Sensor signal conditioning module for sheet cutting equipment

Baichao old Poscon system supporting signal board

The BYSTRONIC E715-5-Q control board is a dedicated signal board for Baichao sheet metal laser processing equipment, ensuring stable transmission of equipment motion signals
