TSXDMZ28DTK Input/Output DC Module

TSXDMZ28DTK Input/Output DC Module

 Introduction

TSXDMZ28DTK Input/Output DC Module

1. Schneider Modicon TSX Micro series PLC hybrid IO module

2.16 channels of 24VDC digital input, 12 channels of transistor solid-state output, totaling 28 points

3.24VDC DC power supply, compatible with proximity switches and sensor inputs

4. Single channel output of 0.5A, driving loads such as solenoid valves and indicator lights

5. Channel short circuit, overcurrent electronic protection, reverse connection protection

6. Optoelectronic isolation to suppress on-site electromagnetic interference

7. HE-10 connector wiring, easy to disassemble and maintain

8. DIN rail installation, compatible with control cabinet assembly

9. Fast input-output response speed, ≤ 0.5ms

10. Panel LED status light, check the on/off status of each channel

11. Wide temperature range -10 ℃~60 ℃, suitable for industrial cabinet working conditions

12. Can be directly connected to the PLC backplane bus expansion point

13. Supports positive logic signals and is compatible with two-wire and two-wire sensors

14. Compact module, saving cabinet installation space

15. Complies with IEC industrial electrical standards

TSXDMZ28DTK is a PLC digital expansion module, commonly used for mechanical and production line automation logic control.

Product imag
