ALSTOM CDG11AF9007ACH Ground Fault Relay

ALSTOM CDG11AF9007ACH Ground Fault Relay

 Introduction

ALSTOM CDG11AF9007ACH Ground Fault Relay

1. ALSTOM CDG11AF9007ACH belongs to IDMT inverse time induction disc protection relay

2. Mainly achieve grounding fault and overcurrent protection functions

3. Self powered design, no need for external auxiliary power supply

4. Multi level current plug-in adjustment, adjustable setting value with power on

5. Adjustable time multiplier knob, matched with graded protection timing

6. High torque drive mechanism, stable operation under harsh working conditions

7. Low overshoot characteristic reduces the risk of misoperation

8. With action indication, manually reset to view fault records

9. Equipped with a high instantaneous unit, it can quickly trip in case of short circuit faults

10. Low load consumption, suitable for current transformer circuits

11. Dustproof plug-in shell, easy installation and maintenance of cabinet body

12. Moisture resistant treatment, suitable for industrial site environment

13. Metal contacts, capable of withstanding long-term frequent movements

14. Compliant with BS industrial protection relay standards

15. ALSTOM CDG11AF9007ACH is used for grounding protection of feeders and transformers

ALSTOM CDG11AF9007ACH grounding fault relay is used for grounding fault and overcurrent inverse time protection in industrial electrical systems, and is used for fault detection and tripping of transformers and feed circuits.

Product imag
