VIDEOJET AT2500-BPLN-08 Backboard PCB Board

VIDEOJET AT2500-BPLN-08 Backboard PCB Board

 Introduction

VIDEOJET AT2500-BPLN-08 Backboard PCB Board

1. VIDEOJET AT2500-BPLN-08 is compatible with the AT2500 series inkjet printer system

2. As a system backplane, it carries the electrical interconnection communication of various functional boards

3. Multiple sets of gold finger slots, which can be plugged into the main control IO、 Nozzle driver board

4. Multi layer PCB wiring ensures power and signal separation without interference

5. Onboard power distribution circuit, distributing power to each sub board

6. Impedance optimization routing ensures stable and distortion free high-speed signal transmission

7. Industrial FR-4 substrate, resistant to workshop dust and oil pollution environment

8. Reserve positioning buckle holes for stable installation inside the cabinet

9. Equipped with surge protection to suppress voltage surges in the power supply circuit

10. Test points on the board for easy on-site maintenance and measurement of signals

11. Support parallel operation of multiple modules to achieve collaborative coding of the entire machine

12. Anti vibration PCB process, suitable for continuous vibration conditions on production lines

13. Signal filtering and wiring to reduce electromagnetic interference in industrial sites

14. Standardized board size, high utilization of internal space of the whole machine

15. Compatible with expansion cards of the same series, convenient for later hardware upgrades

VIDEOJET AT2500-BPLN-08 backboard PCB board is the backboard of the entire Weidijie AT2500 inkjet printer, which realizes the power supply and signal interconnection of various boards in the machine

Product imag
