PASABAN MTC-3001 Drive Control Module

PASABAN MTC-3001 Drive Control Module

 Introduction

PASABAN MTC-3001 Drive Control Module

1. PASABAN MTC-3001 is compatible with MTC-3044 rack control system

2. Support vector motion control of servo motors and induction motors

3. Equipped with dual closed-loop control of torque loop and speed loop

4. Compatible with differential encoder signal acquisition input

5. Equipped with onboard digital oscilloscope, online observation of operating parameters

6. Support fiber optic output interface and interface with high-speed metering module

7. Built in fault history record, convenient for fault tracing and troubleshooting

8. Support DC bus energy regeneration and adapt to braking conditions

9. Digital display of onboard status for intuitive viewing of alarm information

10. Snap on backboard plug, can be quickly disassembled and replaced on site

11. Industrial grade protection, resistant to vibration and dust interference in paper making workshops

12. Equipped with multiple protection mechanisms for overcurrent, overheating, and overload

13. Support Codesys function blocks for easy program configuration and debugging

14. Internal high-speed bus, real-time communication with system modules

15. Support multi axis collaboration to meet the synchronous control of paper equipment

PASABAN MTC-3001 drive control module, mainly used for papermaking equipment, to complete motor drive and motion closed-loop control.

Product imag
