Alstom SKD11BF8003BCH synchronous relay

Alstom SKD11BF8003BCH synchronous relay

 Introduction

Alstom SKD11BF8003BCH synchronous relay

1. Implement multi loop phase synchronization detection and complete synchronous closing logic judgment

2. Multiple sets of isolated contact outputs, outputting synchronous ready switch signals

3. Installation of rail mounted cabinets, easy disassembly, debugging, and maintenance operation

4. The phase threshold can be adjusted on-site to adapt to different synchronous working conditions

5. Fast action response speed, ensuring synchronous closing timing accuracy

6. Capable of step loss discrimination and outputting locking signals in abnormal states

7. Surge suppression of coil circuit to reduce power grid impact interference

8. Stable mechanical structure and vibration resistance suitable for industrial sites

9. Wide temperature working range, reliable operation in high and low temperature environments

10. EMC electromagnetic compatibility, resistant to strong electromagnetic interference on site

11. The working status is visible, which facilitates on-site debugging and troubleshooting

12. Compact and compact structure, saving installation space for control cabinets

13. Support multiple units to cooperate and achieve synchronous control of multiple units

14. Electrical isolation design to avoid mutual interference between the front and rear circuits

15. Adapt to Alstom transmission and generator synchronization system

Alstom SKD11BF8003BCH synchronous relay, phase synchronization detection component, commonly used for synchronous interlocking control circuits of generator sets and transmission equipment.

Product imag
