TEL 3308-000087-13 Control Board

TEL 3308-000087-13 Control Board

 Introduction

TEL 3308-000087-13 Control Board

1. 3308-000087-13 is compatible with TEL semiconductor etching equipment for supporting control operations

2. Coordinate the timing linkage control instructions of various executing components within the machine

3. Electrical isolation between boards to prevent external surge voltage from damaging the core chip

4. Onboard status indicator light, visually viewing abnormal operation and channel conditions

5. 3308-000087-13 comes with overcurrent and overvoltage circuit protection mechanism

6. Backboard slot direct insertion installation, easy and efficient replacement and disassembly inside the cabinet

7. Power off automatically saves process parameters, restart without the need for repeated debugging and setting

8. Optimize the anti-interference design of the circuit and ensure stable operation in the complex electromagnetic environment of the clean workshop

9. Each control channel is independent of each other, and a single fault will not cause the entire machine to shut down

10. Select industrial reinforced components to withstand normal vibrations during equipment operation

11. The power consumption of the whole machine is moderate, and the temperature rise control is good for long-term continuous operation

12. Automatic hardware self-test upon startup, quickly locate circuit and hardware faults

13. Docking sensors, valve groups, and servo components to achieve closed-loop control

14. Reserve testing and welding inventory positions, making on-site maintenance and inspection easier

15. 3308-000087-13 can execute process control tasks 24/7 without interruption

TEL 3308-000087-13 control board has stable performance and is designed to achieve overall process logic control for semiconductor wafer processing equipment

Product imag
