DNS BP-0168A-S panel switch board

DNS BP-0168A-S panel switch board

 Introduction

DNS BP-0168A-S panel switch board

1. BP-0168A-S integrated multi way switch button for centralized control of equipment start and stop

2. The board layout is neat, and the operation buttons are clearly divided and not easily touched by mistake

3. Equipped with a built-in status indicator light, it provides a visual view of the on/off status of each switch

4. Built in simple overcurrent protection, automatic circuit cut-off for abnormal current

5. BP-0168A-S board dustproof structure reduces dust accumulation faults

6. The wiring terminals are arranged neatly, and on-site wiring and disassembly are simple and fast

7. The board has good insulation and is not prone to short circuits during operation

8. The switch contacts are wear-resistant and durable, and frequent pressing is not easy to cause poor contact

9. Resistant to slight vibrations, stable operation in bumpy environments

10. Compatible with standard chassis openings, directly embedded for installation without modification

11. Low power consumption operation, low temperature rise on the working surface for a long time

12. The circuit layout is resistant to electromagnetic interference, and the signals on the industrial control site are not easily disturbed

13. Support single point independent on-off control, single channel faults do not affect each other

14. The board surface is easy to wipe and clean, and oil stains and dust are easy to maintain

15. BP-0168A-S is compatible with conventional DC power supply and most industrial control equipment

DNS BP-0168A-S panel switch board is easy to operate and reliable in protection, and is commonly used for manual control panels in the front-end of industrial control equipment

Product imag
