ACS SB-14221-104 Motion Control Module

ACS SB-14221-104 Motion Control Module

 Introduction

ACS SB-14221-104

1. SB-14221-104 is compatible with precision equipment servo axis matching control acquisition

2. Connect multiple encoder signals to accurately collect motor position data

3. Equipped with vibration reduction algorithm to reduce mechanical shaking during platform operation

4. Optoelectronic isolation circuit to avoid electromagnetic interference and misoperation on site

5. Card insertion installation, easy disassembly, replacement, and maintenance of cabinets

6. Equipped with limit and interlocking signal access, ensuring safe operation

7. Equipped with ACS bus communication, good synchronization of multi axis actions

8. Hardware for automatic locking protection against overcurrent, overheating, and stalling

9. Lead free process to meet the requirements of semiconductor cleanroom use

10. Seismic reinforced circuit board, less prone to virtual soldering under vibration conditions

11. Low power operation, stable temperature rise during long-term operation

12. Support dedicated motion programming, easy trajectory debugging

13. Automatically retain fault records for easy on-site maintenance and troubleshooting

14. Real time refreshing of location data, high accuracy of positioning repetition

15. Factory calibration of the entire machine, compatible with wafer inspection and handling equipment

ACS SB-14221-104 high-precision motion control submodule ensures smooth and precise operation of precision workbenches.

Product imag
