ACS SB-14221-100/LF motion control module

ACS SB-14221-100/LF motion control module

 Introduction

ACS SB-14221-100/LF

1. SB-14221-100/LF is a high-precision multi axis motion control sub module for ACS, commonly used for driving and controlling semiconductor precision platforms

2. LF lead-free environmentally friendly process, in line with the environmental regulations of clean rooms

3. Support servo closed-loop position high-speed sampling, high positioning repeatability accuracy

4. Built in vibration suppression algorithm to weaken mechanical resonance caused by high-speed movement of the platform

5. Equipped with multiple high-speed encoder signal connections, accurately reading the real-time position of the motor

6. Modular plug-in card installation, easy to plug, replace and maintain inside the cabinet

7. Integrated digital IO channel, connected to safety interlock and origin limit switch signals

8. The photoelectric isolation circuit isolates external electromagnetic interference, and the instruction execution is not triggered incorrectly

9. Adapt to ACS main control bus communication, with highly consistent multi axis synchronous motion timing

10. Built in overcurrent, overload, and overheating hardware self-locking protection to prevent servo hardware damage

11. Low power circuit design, stable and controllable temperature rise of the whole machine during long-term full load operation

12. Strengthen PCB circuits to prevent virtual soldering and desoldering under reciprocating vibration conditions of equipment

13. Support ACSPL+dedicated motion programming language, simple process trajectory editing and debugging

14. Equipped with built-in fault log storage, abnormal records facilitate on-site troubleshooting and traceability

15. Factory loaded aging calibration, suitable for uninterrupted operation of wafer handling and precision testing platforms

ACS SB-14221-100/LF semiconductor equipment specific motion control daughter card ensures high-precision multi axis linkage, smooth and precise operation.
