 Introduction

MKS PDR-C-2C-BCD

1. PDR-C-2C-BCD output stable ± 15V DC power supply, compatible with capacitive vacuum pressure sensors

2. Dual signal acquisition channels, capable of simultaneously connecting two vacuum gauges to monitor air pressure data

3. Equipped with BCD digital signal output, it can be connected to industrial control host to collect numerical values

4. Four point five digit high-precision digital display, allowing for intuitive viewing of real-time pressure values on site

5. Two independent threshold relays, automatically triggering interlocking action when pressure exceeds the standard

6. The panel knob can be used for coarse and fine dual zero calibration, and the calibration operation is simple

7. Standard half rack specifications, rack rails are installed neatly to save space

8. The maximum output current is 600mA, which is sufficient to drive two sensors to work simultaneously

9. Equipped with automatic channel switching, taking turns reading monitoring data from both channels

10. Built in overcurrent and short circuit protection, abnormal power outage protection for internal circuits

11. Multiple types of pressure units can be freely switched to adapt to different process reading habits

12. Backplane dedicated BCD interface, data latch transmission is less prone to signal loss

13. Industrial grade circuits are resistant to electromagnetic interference, and clean room operation data is stable

14. Integrated metal shell, good heat dissipation effect, low temperature rise during long-term operation

15. Original factory matching semiconductor vacuum chamber, hardware compatibility does not require modification

MKS PDR-C-2C-BCD is a vacuum monitoring dedicated power supply digital display integrated module, which provides stable power supply to vacuum gauges and uploads pressure data.

Product imag
