B&R 80SD100XD. C0XX-01 Stepper Driver

B&R 80SD100XD. C0XX-01 Stepper Driver

 Introduction

B&R 80SD100XD. C0XX-01 Stepper Driver

1. Can drive two two-phase stepper motors simultaneously, B&R 80SD100XD. C0XX-01 achieves dual axis synchronous control

2. Supports up to 256 subdivision drivers, with low vibration during operation and higher positioning accuracy

3. Suitable for 24-64V DC wide voltage supply, stable operation with small voltage fluctuations on site

4. Equipped with X2X bus communication, quickly networked and linked with the main control of B&R

5. Equipped with encoder closed-loop detection, correcting step loss issues and achieving more precise control

6. Equipped with multiple digital input and output terminals, capable of receiving external trigger signals

7. The panel indicator lights intuitively display communication, operation, and fault status

8. Built in comprehensive protection against overcurrent, overvoltage, overheating, and short circuit

9. Electrical isolation design to avoid mutual interference between the bus and power circuit

10. Strong resistance to electromagnetic interference, making it less likely for abnormal errors to occur around the workshop frequency converter

11. Compact body, wall mounted with guide rails, saving control cabinet space

12. Support independent setting to maintain current, reduce standby power consumption and heat generation

13. Paired with accompanying software for visual debugging, parameter settings are simple and convenient

14. Suitable for normal industrial control temperature range of 0-45 ℃, stable long-term continuous operation

15. Factory aging verification of the entire machine, low failure rate in industrial field operation

B&R 80SD100XD. C0XX-01 is an integrated high-precision stepper drive unit, suitable for precise positioning and transmission control of small and medium-sized equipment.

Product imag
