TEL 3281-000124-11 Vision Card

TEL 3281-000124-11 Vision Card

 Introduction

TEL 3281-000124-11 Vision Card

1. 3281-000124-11 is compatible with TEL semiconductor equipment and is responsible for wafer visual image acquisition and processing

2. Standard board specifications, supporting quick plug-in and installation of cabinets

3. High image transmission rate, meeting the requirements of high-speed wafer positioning and detection

4. Equipped with a dedicated image preprocessing circuit, the recognition accuracy is stable

5. Hardware anti-interference design, suitable for complex electromagnetic environments in clean workshops

6. Multi channel camera signal interface, capable of external connection to industrial visual cameras

7. Built in image cache ensures continuous capture of 3281-000124-11 images

8. Support device bus communication and real-time upload of visual inspection data

9. Multi layer PCB wiring reduces image signal distortion and crosstalk

10. Industrial grade components that can operate continuously and stably for a long time

11. Reserve test points for easy troubleshooting and maintenance of board faults

12. Supporting original factory visual algorithms to complete wafer alignment recognition work

13. Onboard signal filtering circuit to improve image signal-to-noise ratio

14. Clear silk screen identification, convenient for on-site wiring and maintenance

15. Modular structure, can be replaced separately after failure

TEL 3281-000124-11 Vision Card, a dedicated image processing board for semiconductor process equipment wafer visual positioning

Product imag
