PI E711B0091 Host Controller Module

PI E711B0091 Host Controller Module

 Introduction

PI E711B0091 Host Controller Module

1. Adapt PI piezoelectric nano positioning platform to achieve precise displacement closed-loop servo control

2. E711B0091 is equipped with a high-speed digital servo chip, which has a fast position response speed

3. Built in high-precision signal acquisition circuit, positioning control accuracy can reach nanometer level

4. Multi channel communication interface, supporting real-time interaction instructions with the main control of semiconductor machines

5. E711B0091 integrates multi-level electrical protection to resist surges and voltage fluctuations

6. Optimize signal filtering circuit to effectively suppress electromagnetic interference caused by machine RF

7. Support trajectory storage and waveform output, adapted to the optical scanning process requirements of wafers

8. Original factory component assembly, after long-term power aging screening and testing

9. E711B0091 modular plug-in structure, time-saving and convenient on-site disassembly and maintenance

10. Equipped with fault diagnosis function, it can record abnormal operation for easy operation and maintenance troubleshooting

11. Gold plated signal connector, maintaining stable contact resistance during long-term continuous operation

12. E711B0091 supports fast calling of servo parameters and easy replacement and debugging of spare parts

13. The internal heat dissipation structure is reasonable, and the temperature rise of the sealed cabinet can be controlled during long-term operation

14. Compatible with supporting capacitive sensors, real-time collection of platform position feedback signals

15. Following the original hardware specifications of PI, modules of the same model can be directly interchanged for use

The PI E711B0091 host controller module is the core control unit of semiconductor lithography and detection equipment nano motion system, widely used for precision platform spare parts replacement.

Product imag

ontroller Module
