 Introduction

AE 2301260-A Controller Module

1. Compatible with AE RF power supply and semiconductor etching and coating process equipment, with original factory standard installation dimensions

2. Responsible for RF power closed-loop regulation and stable output of energy parameters required for the process

3. Built in signal isolation circuit to resist interference from complex electromagnetic environments in vacuum chambers

4. Integrate multiple analog and digital channels to collect voltage, current, and reflected power signals

5. Equipped with multiple protection mechanisms including overcurrent, overvoltage, overtemperature, and standing wave

6. High speed signal processing unit, quickly responding to load changes to maintain process stability

7. Support industrial communication bus to achieve data interoperability with equipment control system

8. Capable of storing process parameters, saving formulas without the need for repeated settings when powered off

9. Equipped with a built-in fault self check alarm, outputting fault codes for quick problem identification

10. Modular board structure, supporting quick disassembly and replacement of racks

11. Optimize PCB strong and weak current partition wiring to reduce signal crosstalk distortion

12. Reserved heat dissipation layout, long-term continuous operation with balanced temperature rise control

13. Industrial grade component selection, capable of withstanding temperature and humidity fluctuations in clean workshops

14. Independent signal circuit design, local abnormalities will not cause the entire machine to shut down

15. Complete aging testing and performance calibration according to AE factory specifications

The AE 2301260-A controller module is the core control unit of the RF power supply, which accurately controls the plasma process power and ensures the consistency of the semiconductor process.
