NIKON 4S001-122-2 power module

NIKON 4S001-122-2 power module

 Introduction

NIKON 4S001-122-2 power module

Compatible with Nikon NSR series lithography equipment, providing centralized power supply for optical and control boards

Multi channel grouping and stable output, each voltage independently regulated to adapt to different precision components

Low ripple filtering circuit, pure power supply without interfering with lens detection signal

Power on soft start design, suppression of surge current protection chamber precision circuit board

Integrated four fold automatic power-off protection for overvoltage, overcurrent, short circuit, and overheating

Multi layer shielding PCB structure to resist RF electromagnetic interference from lithography equipment

Low exhaust components specifically designed for cleanrooms, suitable for dust-free wafer production environments

Built in temperature sensing circuit, real-time monitoring of module temperature rise and uploading fault signals

Optimize the built-in heat dissipation layout, ensuring stable and controllable temperature rise during long-term full load operation

Gold finger direct insertion installation, easy disassembly and replacement of lithography equipment cabinets

Wide voltage input adapted to the factory power grid, with small voltage fluctuations and output without offset

Thickened and reinforced plates and welding points, making it difficult for equipment vibration conditions to cause welding failure

Onboard independent current limiting branch, single load failure does not affect the entire power supply

Original factory aging test for the entire machine, compatible with Nikon lithography equipment of the same model directly

Compact integrated layout, saving installation space for small cabinets inside the equipment

NIKON 4S001-122-2 power module has stable power supply and strong anti-interference ability, and is a spare part of the original dedicated power supply board for semiconductor lithography equipment
